PIP5K1A Antibody / Phosphatidylinositol-4-phosphate 5-kinase type-1 alpha (FY13024)

Immunofluorescent staining of PIP5K1A using anti-PIP5K1A antibody (green) and anti-Beta Tubulin antibody (red). PIP5K1A was detected in an immunocytochemical section of Hela cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 ug/ml rabbit anti-PIP5K1A antibody and mouse anti-Beta Tubulin antibody overnight at 4oC. DyLight 488 Conjugated Goat Anti-Rabbit IgG and Cy3 Conjugated Goat Anti-Mouse IgG were used as secondary antibody at 1:500 dilution and incubated for 30 minutes at 37oC. Visualize using a fluorescence microscope and filter sets appropriate for the label used.

Western blot analysis of PIP5K1A using anti-PIP5K1A antibody. Electrophoresis was performed on a 10% SDS-PAGE gel at 80V (Stacking gel) / 120V (Resolving gel) for 2 hours. Lane 1: human HepG2 whole cell lysates, Lane 2: human Hela whole cell lysates. After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-PIP5K1A antibody at 0.5 ug/ml overnight at 4oC, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal was developed using an ECL Plus Western Blotting Substrate. A single, strong band is observed just below the 70 kDa marker, slightly above the predicted molecular weight of ~63 kDa for PIP5K1A (phosphatidylinositol-4-phosphate 5-kinase type I alpha). The higher apparent migration is consistent with previous studies reporting that PIP5K1A commonly runs at ~68-70 kDa on SDS-PAGE due to its acidic composition and post-translational regulation. In parallel immunoprecipitation experiments, this antibody detects a 75-80 kDa doublet, which likely corresponds to post-translationally modified forms of PIP5K1A. Specifically, phosphorylation of type I PIP5K1A has been shown to produce a mobility shift to higher molecular weight species, while SUMOylation at Lys-244 adds ~11 kDa per modification and can generate discrete slower-migrating bands.

Immunohistochemical staining of PIP5K1A using anti-PIP5K1A antibody. PIP5K1A was detected in a paraffin-embedded section of rat brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 ug/ml rabbit anti-PIP5K1A antibody overnight at 4oC. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37oC. The tissue section was developed using an HRP secondary and DAB substrate.

Immunohistochemical staining of PIP5K1A using anti-PIP5K1A antibody. PIP5K1A was detected in a paraffin-embedded section of mouse brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 ug/ml rabbit anti-PIP5K1A antibody overnight at 4oC. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37oC. The tissue section was developed using an HRP secondary and DAB substrate.

Immunoprecipitating PIP5K1A in 293T whole cell lysate. Western blot analysis of PIP5K1A using anti-PIP5K1A antibody. Lane 1: 293T whole cell lysates (30ug), Lane 2: Rabbit control IgG instead of anti-PIP5K1A antibody in 293T whole cell lysate, Lane 3: anti-PIP5K1A antibody (2ug) + 293T whole cell lysate (500ug). After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PIP5K1A antibody at a dilution of 0.5 ug/ml and probed with a goat anti-rabbit IgG-HRP secondary antibody. The signal is developed using ECL Plus Western Blotting Substrate. Immunoprecipitation–Western blot of PIP5K1A. Although PIP5K1A is ~62-63 kDa (apparent ~66-70 kDa on SDS-PAGE), IP-WB reveals a 75-80 kDa doublet. Published work shows that phosphorylation of type I PIP5K1A causes a mobility shift, and SUMOylation (e.g., at Lys-244) produces slower-migrating species, consistent with the doublet observed here.

Flow Cytometry analysis of HeLa cells using anti-PIP5K1A antibody. Overlay histogram showing HeLa cells stained with (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-PIP5K1A antibody (1 ug/million cells) for 30 min at 20oC. DyLight 488 conjugated goat anti-rabbit IgG (5-10 ug/million cells) was used as secondary antibody for 30 minutes at 20oC. Isotype control antibody (Green line) was rabbit IgG (1 ug/million cells) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.

Immunohistochemical staining of PIP5K1A using anti-PIP5K1A antibody. PIP5K1A was detected in a paraffin-embedded section of human liver cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 ug/ml rabbit anti-PIP5K1A antibody overnight at 4oC. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37oC. The tissue section was developed using an HRP secondary and DAB substrate.

Immunohistochemical staining of PIP5K1A using anti-PIP5K1A antibody. PIP5K1A was detected in a paraffin-embedded section of human liver tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 ug/ml rabbit anti-PIP5K1A antibody overnight at 4oC. Peroxidase Conjugated Goat Anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37oC. The tissue section was developed using an HRP secondary and DAB substrate.
